Lithium ion Battery 12v 300ah Lifepo4 Battery Pack for UPS and Solar Energy System
Lithium ion Battery 12v 300ah Lifepo4 Battery Pack for UPS and Solar Energy System is ideal for the new household energy storage installation. To serve evolving load requirements, modular design can fit your energy demand of today and tomorrow.
Model : 12.8V 300Ah
Lithium ion Battery 12v 300ah Lifepo4 Battery Pack for UPS and Solar Energy System
High protection level
IP65
Higher Power
Delivers twice power of lead acid battery.
Higher discharge rate, while maintaining high energy capacity.
Longer Cycle Life
Offers up to 50000 times longer cycle life andfve times longer float/calendar life than lead acid battery.
Superior Safety
Lithium lron Phosphate chemistry eliminates the risk of explosionor combustion due to high impact, overcharging or short circuit.
Lithium ion Battery 12v 300ah Lifepo4 Battery Specification
| Specification | |
| Nominal Voltage | 12.8V |
| Nominal Capacity | 300Ah / 3840Wh |
| BMS | Integrated |
| Cycle Life | >5000 cycles @0.5C / 50%DOD |
| Months Self Discharge | <3% |
| Effciency of Charge | 100% @0.5C |
| Effciency of Discharge | 96~99% @0.5C |
| Charge Voltage | 14.2~14.6V |
| Charge Mode | 0.2C to 14.6V, then change to 0.02C (CC/CV) |
| Recommended Charge Current | 60A |
| Max. Charge Current | 100A |
| Charge Cut-o Voltage | 14.6V±0.2V |
| Max. Continuous Discharge Current | 200A |
| Peak Discharge Current | 800A+-160A (0.5~1.5S) |
| Discharge Cut-o Voltage | 10V±0.5V |
| Charge Temperature | 0°C~55°C @60±25% Relative Humidity |
| Discharge Temperature | -20°C~60°C @60±25% Relative Humidity |
| Storage Temperature | -20°C~45°C @60±25% Relative Humidity |
| Protection Class | IP65 |
| Approx. Dimensions | 521mm*268mm*225mm |
| Approx. Weight | 32kg |
| Terminal | M8 |
| Maximum Modules in Series | 4 |
| Monitoring Option | Bluetooth with Smartphone App |
